GF-326 Series
Manufacturer: CW Industries
Beta
⌘K
SWITCH SLIDE DPDT 3A 125V
| Part | Electrical Life | Mechanical Life | Switch Travel | Actuator Material | Mounting Type | Voltage Rating - AC | Switch Function | Circuit | Contact Material | Contact Timing | Actuator Length [x] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Actuator Type | Termination Style | Voltage Rating - DC | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Through Hole | 125 V | On-On (Line Voltage Selector) | DPDT | Copper | Not Specified | 0.79 mm | -10 °C | 104 °C | Silver | Screwdriver Slot | PC Pin | 125 VDC | 3 A 500 mA |
CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 19.05 mm | -10 °C | 104 °C | Silver | Standard | Solder Lug | 125 VDC | 3 A 500 mA |
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 1.65 mm | -10 °C | 104 °C | Silver | Push-Pull | Solder Lug | 125 VDC | 3 A 500 mA |
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 8.74 mm | -10 °C | 104 °C | Silver | Standard | Solder Lug | 125 VDC | 3 A 500 mA |
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 0.5 in | -10 °C | 104 °C | Silver | Standard | PC Pin | 125 VDC | 3 A 500 mA |
CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 8.74 mm | -10 °C | 104 °C | Silver | Standard | PC Pin | 125 VDC | 3 A 500 mA |
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 8.74 mm | -10 °C | 104 °C | Silver | Standard | Wire Wrap | 125 VDC | 3 A 500 mA |
CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On (Line Voltage Selector) | DPDT | Copper | Not Specified | 0.79 mm | -10 °C | 104 °C | Silver | Screwdriver Slot | Solder Lug | 125 VDC | 3 A 500 mA |
 CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 0.5 in | -10 °C | 104 °C | Silver | Standard | Solder Lug | 125 VDC | 3 A 500 mA |
CW Industries | 6000 Cycles | 10000 Steps | 4.01 mm | Nylon 6/6 Polyamide (PA66) | Panel Mount | 125 V | On-On | DPDT | Copper | Not Specified | 8.74 mm | -10 °C | 104 °C | Silver | Standard | PC Pin | 125 VDC | 3 A 500 mA |
