396-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 15POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Type | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Read Out | Pitch | Pitch | Card Type | Termination | Number of Positions | Gender | Contact Material | Color | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | 15 | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder Wire Wrap | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 15 | Right Angle Through Hole | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.25 Ám | 10 Áin | 15 | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 15 | Through Hole | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 15 | Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder Wire Wrap | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 0.25 Ám | 10 Áin | 15 | Right Angle Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 15 | Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Wire Wrap | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 0.25 Ám | 10 Áin | 15 | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder Wire Wrap | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 15 | Right Angle Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 1 | -40 C | 105 ░C | Gold | Single | 3.18 mm | 0.125 in | Non Specified - Single Edge | Solder Wire Wrap | 15 | Female | Copper Alloy | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | 15 | Right Angle Through Hole |
