627-17W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 17POS VERT SLDR
| Part | Dielectric Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Termination | Connector Style | Mounting Type | Material Flammability Rating | Flange Feature | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Features | Contact Finish | Number of Positions | Number of Rows [custom] | Connector Type | Current Rating (Amps) | Shell Material, Finish | Contact Type | Shell Size, Connector Layout | Contact Finish Thickness | Number of Positions [custom] | Number of Positions [custom] | Current Rating (Amps) | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | 30 Áin | 0.76 Ám | Solder | Combo D-Sub | Through Hole | UL94 V-0 | Board Side (M3) | 4 | DC C - 17W5 | Board Lock Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | 20A 5A | Nickel Plated Steel | Signal and Power | |||||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Combo D-Sub | Free Hanging (In-Line) | UL94 V-0 | Housing/Shell (Unthreaded) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | 10A 5A | Signal and Power | 17W2 | Flash | |||||||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | 30 Áin | 0.76 Ám | Solder | Combo D-Sub | Panel Mount Through Hole | UL94 V-0 | Board Side (M3) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | Nickel Plated Steel | Coax Signal | 17W2 | 15 Positions | 2 | |||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Solder | Combo D-Sub | Panel Mount Through Hole | UL94 V-0 | Board Side (4-40) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | Signal and Power | 17W2 | Flash | 5 A 40 A | ||||||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | 30 Áin | 0.76 Ám | Solder | Combo D-Sub | Panel Mount Through Hole | UL94 V-0 | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | Nickel Plated Steel | Coax Signal | 17W2 | 15 Positions | 2 | 4-40 | 4-40 | ||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Combo D-Sub | Free Hanging (In-Line) | UL94 V-0 | Board Side (4-40) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | 10A 5A | Signal and Power | 17W2 | Flash | |||||||||
 EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Solder | Combo D-Sub | Panel Mount Through Hole | UL94 V-0 | Board Side (M3) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | 20A 5A | Nickel Plated Steel | Signal and Power | 17W2 | Flash | |||||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Solder | Combo D-Sub | Through Hole | UL94 V-0 | Board Side (4-40) | 4 | DC C - 17W5 | Board Lock Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | Signal and Power | Flash | 5 A 30 A | |||||||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | Solder | Combo D-Sub | Panel Mount Through Hole | UL94 V-0 | Board Side (M3) | 3 | B DB | Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | Coax Signal | 17W2 | Flash | 15 Positions | 2 | |||||||
EDAC Inc. | Polyester Thermoplastic | 125 VDC | -55 C | 125 °C | Black | Copper Alloy | 30 Áin | 0.76 Ám | Solder | Combo D-Sub | Through Hole | UL94 V-0 | Board Side (4-40) | 4 | DC C - 17W5 | Board Lock Grounding Indents Shielded | Gold | 17 | 2 | Plug Male Pins | 10A 5A | Nickel Plated Steel | Signal and Power |
