CB2 Series
Manufacturer: ITT Cannon, LLC
Beta
⌘K
CONN RCPT 12POS BOX MNT PIN
| Part | Qualification | Orientation | Ingress Protection | Color | Number of Positions | Fastening Type | Shell Material | Connector Type | Contact Finish - Mating | Mounting Feature | Voltage Rating | Shell Finish | Current Rating (Amps) | Primary Material | Shell Size - Insert | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size - Insert [Min] | Shell Size - Insert [Max] | Termination | Insert Material | Contact Shape | Note | Shielding | Contact Size | Contact Type | Type | Housing Color | Orientation [x] | Shell Size - Insert |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | 12 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Male Pins | Gold | Flange | 50 V | Olive Drab Cadmium | 41 A | Metal | 24-A24 | Panel Mount | -55 C | 125 °C | |||||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | 16 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Male Pins | Gold | Flange | 50 V | Olive Drab Cadmium | 22 A 41 A | Metal | Panel Mount | -55 C | 125 °C | 24 | 7 | ||||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Female Sockets | Silver | Flange | 50 V | Olive Drab Cadmium | 74 A | Metal | 22-2 | Panel Mount | -55 C | 125 °C | Crimp | |||||||||||||
 ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | 35 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Housing | Flange | Chromate over Cadmium | Panel Mount | -55 C | 125 °C | 28 | 15 | Polychloroprene | Circular | Contacts Not Included | Unshielded | 16 | Crimp Solder Solder Cup | For Female Sockets | Olive Drab | |||||||||
 ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Male Pins | Silver | Flange | 50 V | Olive Drab Cadmium | 22 A | Metal | Panel Mount | -55 C | 125 °C | 18 | 22 | Crimp | ||||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | 54 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Male Pins | Silver | Flange | 50 V | Olive Drab Cadmium | 22 A | Metal | 32-A10 | Panel Mount | -55 C | 125 °C | Crimp | ||||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | N (Normal) | IP67 - Dust Tight Waterproof | Olive Drab | 16 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Female Sockets | Gold | Flange | 50 V | Olive Drab Cadmium | 22 A | Metal | Panel Mount Through Hole | -55 C | 125 °C | 24 | 5 | Solder | |||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | IP67 - Dust Tight Waterproof | 37 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Housing | Flange | Chromate over Cadmium | Panel Mount | -55 C | 125 °C | Polychloroprene | Circular | Contacts Not Included | Unshielded | 16 | Crimp Solder Solder Cup | For Female Sockets | Olive Drab | X | 21 28 | ||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | W | IP67 - Dust Tight Waterproof | Olive Drab | 26 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Male Pins | Silver | Flange | 50 V | Olive Drab Cadmium | 22 A | Metal | Panel Mount | -55 C | 125 °C | 28 | 12 | Crimp | |||||||||||
ITT Cannon, LLC | MIL-DTL-5015 | W | IP67 - Dust Tight Waterproof | 19 | Reverse Bayonet Lock | Aluminum Alloy | Receptacle Housing | Flange | Chromate over Cadmium | 22-14 | Panel Mount | -55 C | 125 °C | Polychloroprene | Circular | Contacts Not Included | Unshielded | 16 | Crimp Solder Solder Cup | For Female Sockets | Olive Drab |
