TPS53681 Series
Manufacturer: Texas Instruments
Beta
⌘K
DUAL-CHANNEL 6+2/5+3 D-CAP+TM MULTIPHASE STEP-DOWN CONTROLLER WITH PMBUS AND NVM
| Part | Number of Outputs | Mounting Type | Topology | Output Configuration | Synchronous Rectifier | Voltage - Supply (Vcc/Vdd) [Min] | Voltage - Supply (Vcc/Vdd) [Max] | Output Phases | Clock Sync | Output Type | Serial Interfaces | Supplier Device Package | Function | Control Features | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Frequency - Switching [Min] | Frequency - Switching [Max] | Voltage - Output | Supplied Contents | Current - Output | Frequency - Switching | Main Purpose | Utilized IC / Part | Board Type | Regulator Topology | Voltage - Input [Min] | Voltage - Input [Max] | Outputs and Type | Outputs and Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 2 | Surface Mount | Buck | Positive | 4.5 V | 17 V | 8 | PWM Signal | PMBus | 40-WQFN (5x5) | Step-Down | Current Limit Enable | 40-WFQFN Exposed Pad | -40 °C | 125 ¯C | 300 kHz | 1 MHz | ||||||||||||||
Texas Instruments | 2 | Surface Mount | Buck | Positive | 4.5 V | 17 V | 8 | PWM Signal | PMBus | 40-WQFN (5x5) | Step-Down | Current Limit Enable | 40-WFQFN Exposed Pad | -40 °C | 125 ¯C | 300 kHz | 1 MHz | ||||||||||||||
 Texas Instruments | 0.9 V | Board(s) | 294 A | 500 kHz | DC/DC Step Down | TPS53681 | Fully Populated | Buck | 10 V | 14 V | 2 | Non-Isolated |
