837-019 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FMALE 19POS 0.156
| Part | Contact Type | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Contact Material | Mounting Type | Number of Rows | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions | Number of Positions/Bay/Row [custom] | Contact Finish | Flange Feature | Card Type | Color | Material - Insulation | Pitch [x] | Pitch [x] | Gender | Contact Finish Thickness | Contact Finish Thickness | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Cantilever | Wire Wrap | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | M3 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | ||||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Top Mount Opening Unthreaded | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 0.156 in | 3.96 mm | ||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | M3 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | ||||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Floating Bobbin Top Mount Opening | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 0.116 in | 2.95 mm | ||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Side Mount Opening Unthreaded | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Floating Bobbin Flush Mount | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 0.116 in | 2.95 mm | ||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | 4-40 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | ||||
EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Side Mount Opening Unthreaded | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Cantilever | Solder | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | ||||
 EDAC Inc. | Cantilever | Wire Wrap | 125 °C | -40 °C | 1 | Copper Alloy | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 19 | 19 | Gold | Top Mount Opening Unthreaded | Non Specified - Single Edge | Green | Diallyl Phthalate (DAP) | 0.156 in | 3.96 mm | Female | 10 Áin | 0.25 Ám | Single | 0.156 in | 3.96 mm |
