SFW7R Series

Catalog

CONN FPC BOTTOM 7POS 1MM R/A

Part	Housing Color	Actuator Color	Mating Cycles	Locking Feature	Voltage Rating	FFC, FCB Thickness	Contact Finish	Height Above Board [z]	Height Above Board [z]	Material Flammability Rating	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Flat Flex Type	Actuator Material	Housing Material	Connector/Contact Type	Pitch	Pitch	Cable End Type	Number of Positions	Contact Material	Mounting Type	FFC, FCB Thickness [custom]	FFC, FCB Thickness [custom]	Features
Amphenol ICC (FCI) SFW7R-3STE5LF	Black	Brown	20	Slide Lock	100 V	0.3 mm	Tin	0.106 in	2.7 mm	UL94 V-0	Solder	-55 C	105 ░C	FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Bottom	1 mm	0.039 in	Notched	7	Phosphor Bronze	Right Angle Surface Mount
Amphenol ICC (FCI) SFW7R-2STE1LF	Brown	Black	20	Slide Lock	100 V		Tin	0.106 in	2.7 mm	UL94 V-0	Kinked Pin	-55 C	105 ░C	FFC FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Top	1 mm	0.039 in	Straight Tapered	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW7R-4STE1LF	Black	Brown	20	Slide Lock	100 V		Tin	0.106 in	2.7 mm	UL94 V-0	Solder	-55 C	105 ░C	FFC FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Top	1 mm	0.039 in	Notched Tapered	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm	Solder Retention Zero Insertion Force (ZIF)
Amphenol ICC (FCI) SFW7R-3STAE5LF	Black	Brown		Slide Lock		0.33 mm	Gold	0.106 in	2.7 mm	UL94 V-0	Solder			FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Bottom	1 mm	0.039 in	Tabbed	7	Phosphor Bronze	Right Angle Surface Mount
Amphenol ICC (FCI) SFW7R-2STAE1LF	Brown	Black	20	Slide Lock	100 V		Gold	0.106 in	2.7 mm	UL94 V-0	Kinked Pin	-55 C	105 ░C	FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Top	1 mm	0.039 in	Straight Tapered	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW7R-3STE1	Black	Brown		Slide Lock			Tin Alloy	0.106 in	2.7 mm	UL94 V-0	Solder			FFC FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Bottom	1 mm	0.039 in	Notched	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW7R-2STE1	Brown	Black		Slide Lock			Tin Alloy	0.106 in	2.7 mm	UL94 V-0	Solder			FFC FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Top	1 mm	0.039 in	Straight Tapered	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW7R-6STE1LF	Brown	Black	10	Slide Lock	100 V	0.3 mm	Tin	0.106 in	2.7 mm	UL94 V-0	Solder	-55 C	105 ░C	CIC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Top	1 mm	0.039 in	Tapered	7	Phosphor Bronze	Right Angle Surface Mount
Amphenol ICC (FCI) SFW7R-1STE1LF	Brown	Black	20	Slide Lock	100 V		Tin	0.106 in	2.7 mm	UL94 V-0	Kinked Pin	-55 C	105 ░C	FFC FPC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Bottom	1 mm	0.039 in	Straight Tapered	7	Phosphor Bronze	Right Angle Surface Mount	0.3 mm	0.33 mm
Amphenol ICC (FCI) SFW7R-5STE1LF	Brown		10		100 V	0.3 mm	Tin	0.106 in	2.7 mm	UL94 V-0	Kinked Pin	-55 C	105 ░C	CIC	Polyphenylene Sulfide (PPS) Glass Filled	Polyphenylene Sulfide (PPS) Glass Filled	Contacts Bottom	1 mm	0.039 in	Straight or Tapered	7	Phosphor Bronze	Right Angle Surface Mount
