ENW-89 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
RF TXRX MODULE BLUETOOTH SMD
| Part | Frequency | Power - Output | Serial Interfaces | Package / Case | Sensitivity | Operating Temperature [Max] | Operating Temperature [Min] | Modulation | Antenna Type | Utilized IC / Part | Protocol | RF Family/Standard | Mounting Type | Current - Receiving | Voltage - Supply [Min] | Voltage - Supply [Max] | Data Rate | Current - Transmitting | Memory Size [custom] | Memory Size [custom] | Memory Size [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | 2.4 GHz | 10 dBm | I2S UART | Module | -93 dBm | 85 °C | -40 °C | GFSK | Antenna Not Included | CC2564 | Bluetooth v4.0 | Bluetooth | Surface Mount | 33 mA | 1.7 V | 4.8 V | 3 Mbps | ||||
 Panasonic Industrial Automation Sales | 2.4 GHz | 10 dBm | I2S UART | PCB Module | -93 dBm | 70 °C | -20 C | GFSK | Antenna Not Included | CC2567 | Bluetooth v4.0 | Bluetooth | Surface Mount | 33 mA | 1.7 V | 4.8 V | 3 Mbps | ||||
 Panasonic Industrial Automation Sales | 2.4 GHz | 10 dBm | I2S UART | Module | -93 dBm | 85 °C | -40 °C | GFSK | Integrated Chip | CC2564B | Bluetooth v4.0 | Bluetooth | Surface Mount | 33 mA | 1.7 V | 4.8 V | 3 Mbps | ||||
Panasonic Industrial Automation Sales | 2.4 GHz | 10.5 dBm | I2S UART | Module | -93 dBm | 85 °C | -40 °C | GFSK | Antenna Not Included | Si1000 | Bluetooth v2.1 +EDR | Bluetooth | Surface Mount | 40 mA | 1.7 V | 4.8 V | 3 Mbps | 40 mA | |||
Panasonic Industrial Automation Sales | 2.4 GHz | 10 dBm | I2S UART | Module | -93 dBm | 85 °C | -40 °C | GFSK | Antenna Not Included | Bluetooth v4.0 | Bluetooth | Surface Mount | 33 mA | 1.7 V | 4.8 V | 3 Mbps | |||||
 Panasonic Industrial Automation Sales | 2.4 GHz | 0 dBm | I2C SPI UART | Module | -93 dBm | 85 °C | -40 °C | Integrated Chip | CC2541 | Bluetooth v4.0 | Bluetooth | Surface Mount | 2 V | 3.6 V | 10 kbps | 14.3 mA | 256 kB | 8 kB | |||
 Panasonic Industrial Automation Sales | 2.4 GHz | 10 dBm | I2S UART | Module | -93 dBm | 85 °C | -40 °C | GFSK | Integrated Chip | CC2567 | Bluetooth v4.0 | Bluetooth | Surface Mount | 33 mA | 1.7 V | 4.8 V | 3 Mbps | ||||
 Panasonic Industrial Automation Sales | 2.4 GHz | 0 dBm | Module | -93 dBm | 85 °C | -40 °C | Integrated Chip | Bluetooth v4.0 Dual Mode | Bluetooth | Surface Mount | 4.9 mA | 2.35 V | 3.3 V | 4.9 mA | |||||||
 Panasonic Industrial Automation Sales | 2.4 GHz | 0 dBm | I2C UART | Module | -90 dBm | 85 °C | -40 °C | ASK | Antenna Not Included | TC35670 | Bluetooth v4.1 | Bluetooth | Surface Mount | 1.7 V | 3.6 V | 424 kbps | 32 kB | 512 kB | |||
 Panasonic Industrial Automation Sales | 2.4 GHz | 4 dBm | SPI UART USB | PCB Module | -93 dBm | 85 °C | -40 °C | Integrated Chip | CC2540 | Bluetooth v4.0 | Bluetooth | Surface Mount | 2 V | 3.6 V | 10 kbps | 18.2 mA | 256 kB | 8 kB |
