RZE50 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN EDGE DUAL FML 100POS 0.039
| Part | Material - Insulation | Termination | Number of Positions/Bay/Row | Gender | Card Type | Contact Finish Thickness | Contact Finish Thickness | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Color | Card Thickness | Card Thickness | Contact Type | Contact Material | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish | Pitch | Pitch | Number of Rows [custom] | Number of Positions | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Solder Staggered | 50 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Dual | -65 ░C | 125 °C | Right Angle Through Hole | Black | 1.57 mm | 0.062 in | Hairpin Bellows | Phosphor Bronze | 0.125 " | Side Mount Opening Unthreaded | 3.18 mm | Gold | 1 mm | 0.039 in | 2 | 100 | |
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Solder Staggered | 50 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Dual | -65 ░C | 125 °C | Through Hole | Black | 1.57 mm | 0.062 in | Hairpin Bellows | Phosphor Bronze | Gold | 1 mm | 0.039 in | 2 | 100 | ||||
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | Solder | 50 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Dual | -65 ░C | 125 °C | Surface Mount | Black | 1.57 mm | 0.062 in | Hairpin Bellows | Phosphor Bronze | Gold | 1 mm | 0.039 in | 2 | 100 | Board Lock |
