ATA02CC Series

Catalog

DC DC CONVERTER +/-15V 8W

Part	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Type	Voltage - Input (Min) [Min]	Mounting Type	Current - Output (Max) [Max]	Current - Output (Max) [Max]	Voltage - Isolation	Number of Outputs	Applications	Features	Voltage - Output 1	Voltage - Input (Max) [Max]	Package / Case	Power (Watts)	Voltage - Output 2
ARTESYN / Advanced Energy ATA02CC18-L	80 ¯C	-40 °C	86 %	0.31 "	0.94 in	0.54 in	13.7 mm	23.8 mm	8 mm	Isolated Module	9 V	Through Hole	265 mA	265 mA	1.5 kV	2	ITE (Commercial)	OCP SCP UVLO	15 V	36 V	16-DIP Module 6 Leads	8 W	-15 V
ARTESYN / Advanced Energy ATA02CC36-L	85 °C	-40 C	86 %	0.31 "	0.94 in	0.54 in	13.7 mm	23.8 mm	8 mm	Isolated Module	18 V	Through Hole	265 mA	265 mA	1.5 kV	2	ITE (Commercial)	OCP SCP	15 V	75 V	16-DIP Module 6 Leads	8 W	-15 V
