R19184 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA MALE - SMP FEMALE ADAPTER
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Center Contact Material | Body Material | Body Finish | Adapter Series | Convert From (Adapter End) | Conversion Type | Style | Fastening Type | Impedance | Convert To (Adapter End) | Adapter Type | Mounting Type | Center Contact Plating | Frequency - Max [Max] | Features | Center Gender | Mating Cycles | Mounting Feature | Center Contact Finish | Connector Style | Color | For Use With/Related Products |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Beryllium Copper | Gold | SMA to SMP | Male Pin SMA Plug | Between Series | Straight | Snap-On Threaded | 50 Ohms | SMP Jack Female Socket | Plug to Jack | Free Hanging (In-Line) | Gold | 18 GHz | ||||||||
 Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Snap-On Threaded | 50 Ohms | Plug to Jack | Free Hanging (In-Line) | Gold | 18 GHz | Full Detent | |||||||||
Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Male Pin SMA Plug | Between Series | Straight | Snap-On Threaded | 50 Ohms | Plug to Plug | Free Hanging (In-Line) | Gold | 18 GHz | Full Detent | Male to Male | ||||||||
Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Beryllium Copper | Gold | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Snap-On Threaded | 50 Ohms | SMP Jack Female Socket | Jack to Jack | Free Hanging (In-Line) | Gold | 18 GHz | Female to Female | |||||||
Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Snap-On Threaded | 50 Ohms | Plug to Jack | Free Hanging (In-Line) | Gold | 18 GHz | Full Detent | |||||||||
 Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Male Pin SMA Plug | Between Series | Straight | Snap-On Threaded | 50 Ohms | Plug to Plug | Free Hanging (In-Line) | Gold | 18 GHz | Full Detent | Male to Male | ||||||||
 Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Snap-On Threaded | 50 Ohms | Plug to Jack | Panel Mount | Gold | 18 GHz | Smooth Bore | 500 | Flange | |||||||
Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Stainless Steel | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Push-Pull Threaded | 50 Ohms | Plug to Jack | Panel Mount | Gold | 18 GHz | Flange | |||||||||
 Radiall USA, Inc. | Beryllium Copper Brass | Brass | Gold | Gold | SMA | Gold | SMP Plugs | ||||||||||||||||||
 Radiall USA, Inc. | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Beryllium Copper | Gold | SMA to SMP | Female Socket SMA Jack | Between Series | Straight | Snap-On Threaded | 50 Ohms | SMP Jack Female Socket | Jack to Jack | Free Hanging (In-Line) | Gold | 18 GHz | Female to Female |
