PGC20 Series

Catalog

CONN HEADER VERT 20POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Current Rating (Amps)	Contact Finish - Mating	Overall Contact Length	Overall Contact Length	Number of Positions Loaded	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Connector Type	Insulation Height	Insulation Height	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Number of Positions	Insulation Color	Contact Shape	Contact Finish - Post	Shrouding	Termination	Style	Contact Material	Insulation Material	Contact Length - Post	Contact Length - Post	Contact Length - Mating	Contact Length - Mating	Contact Type	Mounting Type	Fastening Type
Sullins Connector Solutions PGC20SZDN	0.127 µm	5 µin	3 A	Gold	21.08 mm	0.83 "	All	1	0.25 µm	10 µin	Header	0.1 in	2.54 mm	UL94 V-0	0.1 "	2.54 mm	20	Black	Square	Gold	Unshrouded	Solder	Board to Board Cable	Copper Alloy	Polyester Thermoplastic	15.49 mm	0.61 in	0.12 in	3.05 mm	Male Pin	Through Hole	Push-Pull
