MT160 Series

Catalog

SILICON CONTROLLED RECTIFIER,

Part	Current - On State (It (AV)) (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Off State	Current - Hold (Ih) (Max) [Max]	Mounting Type	Current - Non Rep. Surge 50, 60Hz (Itsm)	Number of SCRs, Diodes	Structure	Current - Gate Trigger (Igt) (Max) [Max]	Package / Case
Micro Commercial Components MT160C18T2-BP	160 A	-40 °C	130 °C	1.8 kV	400 mA	Chassis Mount	5400 A	2 SCRs	Series Connection - All SCRs	150 mA	Module
Micro Commercial Components MT160C08T2-BP	160 A	-40 °C	130 °C	800 V	400 mA	Chassis Mount	5400 A	2 SCRs	Series Connection - All SCRs	150 mA	Module
