170-025 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB HOUSING, RCPT, 25POS, DB ROHS COMPLIANT: YES
| Part | Note | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Shell Material, Finish | Number of Positions | Mounting Type | Connector Style | Flange Feature | Connector Type | Contact Type | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | Nickel Plated Steel | 25 | Free Hanging (In-Line) | D-Sub | 4-40 | Receptacle for Female Contacts | Signal | B DB | 3 | 2 | |
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Receptacle for Female Contacts | Signal | B DB | 3 | 2 | ||
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) Glass Filled | 125 °C | -50 °C | Nickel Plated Steel | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Plug for Male Contacts | Signal | B DB | 3 | 2 | Grounding Indents | |
NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | Nickel Plated Steel | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Receptacle for Female Contacts | Signal | B DB | 3 | 2 | |
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Receptacle for Female Contacts | Signal | B DB | 3 | 2 | ||
NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Plug for Male Contacts | Signal | B DB | 3 | 2 | ||
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) Glass Filled | 125 °C | -50 °C | Nickel Plated Steel | 25 | Free Hanging (In-Line) | D-Sub | Housing/Shell (Unthreaded) | Plug for Male Contacts | Signal | B DB | 3 | 2 | Grounding Indents | |
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) Glass Filled | 125 °C | -50 °C | Nickel Plated Steel | 25 | Free Hanging (In-Line) | D-Sub | 4-40 | Plug for Male Contacts | Signal | B DB | 3 | 2 | Grounding Indents | |
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | 25 | Free Hanging (In-Line) | D-Sub | Housing/Shell (Unthreaded) | Receptacle for Female Contacts | Signal | B DB | 3 | 2 | ||
 NorComp Inc. | Contacts Not Included | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | Black | 25 | Free Hanging (In-Line) | D-Sub | Cable Side (4-40) | Plug for Male Contacts | Signal | B DB | 3 | 2 |
