395-082 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 82POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Number of Rows [custom] | Features | Number of Positions/Bay/Row | Color | Mounting Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Read Out | Number of Positions | Gender | Card Type | Flange Feature | Pitch | Pitch | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Extender Card Guides | 41 | Black | Board Edge Straddle Mount | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Guides | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Guides | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | M3 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Wire Wrap | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Extender Card Guides | 41 | Black | Board Edge Straddle Mount | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Guides | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Wire Wrap | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Wire Wrap | 3.96 mm | 0.156 " | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Card Guides | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | 41 | Black | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Dual | 82 | Female | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Copper Alloy | -40 C | 105 ░C | Solder |
