GWQ9LR32 Series

Catalog

LED OSCONIQ SMD

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max)	Mounting Type	Supplier Device Package	Package / Case	Thermal Resistance of Package	Current - Max [Max]	Viewing Angle	Flux @ 85°C, Current - Test [Max]	Flux @ 85°C, Current - Test [Min]	CCT (K)	Color	CRI (Color Rendering Index)	Voltage - Forward (Vf) (Typ)	Current - Test
ams-OSRAM USA INC. GW Q9LR32.PM-M4N3-XX53-1-180-R18	0.197 in	0.197 "	5 mm	5 mm	0.031 in	0.8 mm	Surface Mount	SMD	2020 (5050 Metric)
ams-OSRAM USA INC. GW Q9LR32.PM-M3N2-XX51-1-180-R18	0.197 in	0.197 "	5 mm	5 mm	0.031 in	0.8 mm	Surface Mount	SMD	2020 (5050 Metric)	1.5 °C/W	1.05 A	120 °	300 lm	200 lm	6500 K	Cool White	70	5.52 V	180 mA
ams-OSRAM USA INC. GW Q9LR32.PM-M3N2-XX57-1-180-R18	0.197 in	0.197 "	5 mm	5 mm	0.031 in	0.8 mm	Surface Mount	SMD	2020 (5050 Metric)	1.5 °C/W	1.05 A	120 °	300 lm	200 lm	3000 K	Warm White	70	5.52 V	180 mA
ams-OSRAM USA INC. GW Q9LR32.PM-M3N2-XX52-1-180-R18	0.197 in	0.197 "	5 mm	5 mm	0.031 in	0.8 mm	Surface Mount	SMD	2020 (5050 Metric)
ams-OSRAM USA INC. GW Q9LR32.PM-M3N2-XX56-1-180-R18	0.197 in	0.197 "	5 mm	5 mm	0.031 in	0.8 mm	Surface Mount	SMD	2020 (5050 Metric)
