24-7068 Series
Manufacturer: Kester Solder
Beta
⌘K
SOLDER NO-CLEAN .050" 16AWG 1LB
| Part | Weight | Weight | Shelf Life Start | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Min] | Type | Composition | Form | Form | Diameter [diameter] | Diameter [diameter] | Shelf Life | Melting Point [Max] | Melting Point [Min] | Melting Point [Min] | Melting Point [Max] | Flux Type | Wire Gauge | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kester Solder | 453.59 g | 1 lbs | Date of Manufacture | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 1.27 mm | 0.05 in | 36 Months | 218 °C | 217 °C | 423 °F | 424 °F | No-Clean | 16 AWG 18 SWG | |
 Kester Solder | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 0.38 mm | 0.015 in | 218 °C | 217 °C | 423 °F | 424 °F | Rosin Activated (RA) | 27 AWG 28 SWG | |||||
Kester Solder | Date of Manufacture | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 36 Months | 218 °C | 217 °C | 423 °F | 424 °F | No-Clean | 20 AWG 22 SWG | |||||
 Kester Solder | 453.59 g | 1 lbs | Date of Manufacture | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 36 Months | 218 °C | 217 °C | 423 °F | 424 °F | Water Soluble | 20 AWG 22 SWG | |||
 Kester Solder | 453.59 g | 1 lbs | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 0.51 mm | 0.02 in | 218 °C | 217 °C | 423 °F | 424 °F | Rosin Activated (RA) | 24 AWG 25 mmý | |||
 Kester Solder | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 1.02 mm | 0.04 in | 218 °C | 217 °C | 423 °F | 424 °F | Rosin Activated (RA) | 18 19 | |||||
Kester Solder | Date of Manufacture | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 0.38 mm | 0.015 in | 36 Months | 218 °C | 217 °C | 423 °F | 424 °F | No-Clean | 27 AWG 28 SWG | |||
 Kester Solder | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 1.02 mm | 0.04 in | 218 °C | 217 °C | 423 °F | 424 °F | No-Clean | 18 19 | |||||
 Kester Solder | 453.59 g | 1 lbs | Date of Manufacture | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 1.27 mm | 0.05 in | 36 Months | 218 °C | 217 °C | 423 °F | 424 °F | Water Soluble | 16 AWG 18 SWG | |
Kester Solder | 40 °C 104 F | 10 C 50 F | Wire Solder | Sn96.5Ag3Cu0.5 (96.5/3/0.5) | 1 lb 454 g | Spool | 1.02 mm | 0.04 in | 218 °C | 217 °C | 423 °F | 424 °F | Rosin Activated (RA) | 18 19 |
