6354 Series

Catalog

MULTI-CONDUCTOR CABLES 24 AWG, 6 CONDUCTOR COMMUNICATION CABLE, SHIELDED, 500 FT - SLATE

Part	Shield Material	Shield Coverage	Cable Type	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Number of Conductors	Wire Gauge	Features	Operating Temperature [Max]	Operating Temperature [Min]	Conductor Material	Shield Type	Jacket (Insulation) Material	Conductor Insulation	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Length [x]	Length [x]
ALPHA WIRE 6354 SL002	Aluminum Copper Tinned	65 % 100 %	Multi-Conductor	300 VDC	0.035 in	0.889 mm	Slate	6	24 AWG	Drain Wire	80 °C	-20 ░C	Copper Tinned	Braid Foil	Poly-Vinyl Chloride (PVC)	Foam Polyethylene (FPE)	152.4 m	500 ft	7	32 AWG	6.73 mm	0.265 in	UL Style 2919
ALPHA WIRE 6354 SL005	Aluminum Copper Tinned	65 % 100 %	Multi-Conductor	300 VDC	0.035 in	0.889 mm	Slate	6	24 AWG	Drain Wire	80 °C	-20 ░C	Copper Tinned	Braid Foil	Poly-Vinyl Chloride (PVC)	Foam Polyethylene (FPE)			7	32 AWG	6.73 mm	0.265 in	UL Style 2919	100 ft	30.5 m
ALPHA WIRE 6354 SL001	Aluminum Copper Tinned	65 % 100 %	Multi-Conductor	300 VDC	0.035 in	0.889 mm	Slate	6	24 AWG	Drain Wire	80 °C	-20 ░C	Copper Tinned	Braid Foil	Poly-Vinyl Chloride (PVC)	Foam Polyethylene (FPE)	304.8 m	1000 ft	7	32 AWG	6.73 mm	0.265 in	UL Style 2919
