V24A5H400 Series

Catalog

DC DC CONVERTER 5V 400W

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max) [Max]	Voltage - Isolation	Voltage - Input (Max) [Max]	Features	Mounting Type	Efficiency	Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Output 1	Number of Outputs	Package / Case	Applications	Type	Power (Watts)
Vicor Corporation V24A5H400BN	-40 C	100 °C	80 A	3000 V	36 V	OVP UVLO	Through Hole	84.5 %	18 V	13.7 mm	0.54 "	116.8 mm	4.6 "	55.9 mm	2.2 "	5 V	1	Full Brick	ITE (Commercial)	Isolated Module	400 W
Vicor Corporation V24A5H400BS	-40 C	100 °C	80 A	3000 V	36 V	OVP UVLO	Through Hole	84.5 %	18 V	13.7 mm	0.54 "	116.8 mm	4.6 "	55.9 mm	2.2 "	5 V	1	Full Brick	ITE (Commercial)	Isolated Module	400 W
Vicor Corporation V24A5H400BL2	-40 C	100 °C	80 A	3000 V	36 V	OVP UVLO	Through Hole	84.5 %	18 V	15.7 mm	0.62 in	116.8 mm	4.6 "	55.9 mm	2.2 "	5 V	1	Full Brick	ITE (Commercial)	Isolated Module	400 W
Vicor Corporation V24A5H400BG	-40 C	100 °C	80 A	3000 V	36 V	OVP UVLO	Through Hole	84.5 %	18 V	15.7 mm	0.62 in	116.8 mm	4.6 "	55.9 mm	2.2 "	5 V	1	Full Brick	ITE (Commercial)	Isolated Module	400 W
Vicor Corporation V24A5H400BN3	-40 C	100 °C	80 A	3000 V	36 V	OVP UVLO	Through Hole	84.5 %	18 V	13.7 mm	0.54 "	116.8 mm	4.6 "	55.9 mm	2.2 "	5 V	1	Full Brick	ITE (Commercial)	Isolated Module	400 W
