VGS-50W Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 36V 52W
| Part | Voltage - Output 1 [custom] | Current - Output 1 | Voltage - Isolation | Number of Outputs | Mounting Type | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Input [Max] | Voltage - Input [Min] | Applications | Efficiency | Operating Temperature [Min] | Operating Temperature [Max] | Type | Approval Agency | Power (Watts) | Standard Number | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 36 V | 1.45 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 89 % | -30 °C | 70 °C | Enclosed | CE cURus | 52 W | 60335-1 62368-1 | |
 CUI Inc. | 4.2 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 86 % | -30 °C | 70 °C | Enclosed | CE cURus | 50 W | 60335-1 62368-1 | 12 V | |
CUI Inc. | 36 V | 1.45 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 89 % | -30 °C | 70 °C | Enclosed | CE cURus | 52 W | 60335-1 62368-1 | |
CUI Inc. | 4.2 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 86 % | -30 °C | 70 °C | Conformal Coated Enclosed | CE cURus | 50 W | 60335-1 62368-1 | 12 V | |
CUI Inc. | 10 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 83 % | -30 °C | 70 °C | Enclosed | CE cURus | 50 W | 60335-1 62368-1 | 5 V | |
CUI Inc. | 4.2 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 86 % | -30 °C | 70 °C | Enclosed | CE cURus | 50 W | 60335-1 62368-1 | 12 V | |
CUI Inc. | 2.2 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 88 % | -30 °C | 70 °C | Enclosed | CE cURus | 52 W | 60335-1 62368-1 | 24 V | |
CUI Inc. | 10 A | 4000 V | 1 | Chassis Mount | 3.23 in | 3.9 " | 30 mm | 99 mm | 82 mm | 1.18 in | 305 VAC 430 VDC | 85 VAC 120 VDC | Household Appliances ITE (Commercial) | 83 % | -30 °C | 70 °C | Conformal Coated Enclosed | CE cURus | 50 W | 60335-1 62368-1 | 5 V |
