630-2W2 Series
Manufacturer: EDAC Inc.
Catalog
CONN D-SUB RCPT 2POS R/A SOLDER
...
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Voltage Rating | Connector Style | Connector Type | Number of Rows | Backset Spacing | Backset Spacing | Shell Size, Connector Layout | Number of Positions | Mounting Type | Termination | Material Flammability Rating | Contact Finish Thickness | Contact Finish | Contact Type | Features | Flange Feature | Current Rating (Amps) | Shell Material, Finish | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 9.4 mm | 0.37 in | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Coax | Mounting Brackets | Housing/Shell (M3) | ||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Board Lock | 4-40 | 10 A | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Board Lock Mounting Brackets | M3 | 40 A | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Gold | Power | Board Lock | 4-40 | 40 A | Nickel Plated Steel | 30 Áin | 0.76 Ám | |
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Shielded | Housing/Shell (Unthreaded) | 20 A | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Shielded | Housing/Shell (Unthreaded) | 30 A | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Board Side (M3) | 20 A | Nickel Plated Steel | |||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Gold | Power | Board Lock Mounting Brackets | 4-40 | 40 A | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Board Lock | 4-40 | 20 A | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Receptacle Female Sockets | 1 | 13.2 mm | 0.52 " | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 2 | Right Angle Through Hole | Solder | UL94 V-0 | Flash | Gold | Power | Mounting Brackets | Housing/Shell (M3) | 20 A | Nickel Plated Steel |
