2340321 Series

Catalog

CARD EDGE CONNECTOR, 2 ROW(S), RIGHT ANGLE, SURFACE MOUNT TERMINAL

Part	Pitch [x]	Pitch [x]	Material - Insulation	Number of Positions/Bay/Row	Number of Positions/Bay/Row	Flange Feature	Flange Feature	Flange Feature	Contact Material	Mounting Type	Color	Operating Temperature [Max]	Operating Temperature [Min]	Number of Rows	Gender	Contact Finish Thickness	Contact Finish Thickness	Termination	Card Thickness	Card Thickness	Number of Positions	Read Out	Contact Finish	Card Type	Termination Rows	Contact Type
TE Connectivity Raychem Cable Protection 6-2340321-4	0.6 mm	0.024 in	Liquid Crystal Polymer (LCP)	14 28	14	2.4 mm	Straddle Mount Opening Unthreaded	0.094 in	Copper Alloy	Board Edge Straddle Mount	Black	85 °C	-40 °C	2	Female	0.76 Ám	30 Áin	Solder	0.076 in	1.93 mm	168	Dual	Gold	Non Specified - Dual Edge
TE Connectivity Raychem Cable Protection 9-2340321-1
TE Connectivity Raychem Cable Protection 4-2340321-3
TE Connectivity Raychem Cable Protection 1-2340321-4	0.6 mm	0.024 in	Liquid Crystal Polymer (LCP)	14 28	14	2.4 mm	Straddle Mount Opening Unthreaded	0.094 in	Copper Alloy	Board Edge Straddle Mount	Black			2	Female	0.76 Ám	30 Áin	Solder	0.062 in	1.57 mm	168	Dual	Gold	Non Specified - Dual Edge	2	Cantilever
