2.00mm Pitch Milli-Grid Header, Right-Angle, Through Hole, 24 Circuits, 0.38µm Gold (Au) Selective Plating, Tray, Lead-Free
2.00mm Pitch Milli-Grid Header, Right-Angle, Through Hole, 24 Circuits, 0.38µm Gold (Au) Selective Plating, Tray, Lead-Free
2.00mm Pitch Milli-Grid Header, Right-Angle, Through Hole, 24 Circuits, 0.38µm Gold (Au) Selective Plating, Tray, Lead-Free
| Part | Contact Finish - Mating | Row Spacing - Mating | Row Spacing - Mating | Contact Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Height | Insulation Height | Contact Length - Mating | Contact Length - Mating | Connector Type | Contact Shape | Mounting Type | Number of Rows | Number of Positions Loaded | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Material | Fastening Type | Insulation Material | Pitch - Mating [x] | Pitch - Mating [x] | Shrouding | Applications | Contact Finish - Post | Contact Length - Post | Contact Length - Post | Termination | Number of Positions | Insulation Color | Material Flammability Rating | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 40 | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 22 positions | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 50 | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 44 | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 12 | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 26 | Black | UL94 V-0 | Board to Board Cable |
 Molex | Gold | 0.079 in | 2 mm | Male Pin | 15 µin | 0.38 µm | 4.3 mm | 0.169 " | 4 mm | 0.157 in | Header | Square | Through Hole Right Angle | 2 | All | 2 çm | 78.7 çin | Phosphor Bronze | Push-Pull | Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled | 0.079 in | 2 mm | Unshrouded | Automotive General Purpose Telecommunications | Tin | 0.102 in | 2.6 mm | Solder | 34 | Black | UL94 V-0 | Board to Board Cable |
