INA190-EP Series

Enhanced product, 40-V, bidirectional, ultraprecise current sense amplifier with picoamp IB & EN

Catalog

Enhanced product, 40-V, bidirectional, ultraprecise current sense amplifier with picoamp IB & EN

Part	Amplifier Type	-3db Bandwidth	Voltage - Input Offset	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Slew Rate	Current - Supply	Current - Input Bias	Mounting Type	Voltage - Supply Span (Min) [Min]	Package / Case	Number of Circuits	Voltage - Supply Span (Max) [Max]	Output Type
Texas Instruments INA190A1NDDFREP	Current Sense	45 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V
Texas Instruments V62/21612-01XE	Current Sense	87 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V	Rail-to-Rail Single Ended
Texas Instruments INA190A5NDDFREP	Current Sense	27 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V
Texas Instruments V62/21612-04XE	Current Sense	87 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V	Rail-to-Rail Single Ended
Texas Instruments INA190A4NDDFREP	Current Sense		3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V
Texas Instruments INA190A2NDDFREP	Current Sense	37 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V
Texas Instruments INA190A3NDDFREP	Current Sense	35 kHz	3 µV	TSOT-23-8	-55 °C	150 °C	1 V/µs	48 µA	500 pA	Surface Mount	1.7 V	SOT-23-8 Thin TSOT-23-8	1	5.5 V

Catalog

Enhanced product, 40-V, bidirectional, ultraprecise current sense amplifier with picoamp IB & EN

Key Features

• Supports Defense, Aerospace, and Medical Applications:Temperature range: –55°C to +150°C, TAControlled BaselineOne Assembly/Test SiteOne Fabrication SiteExtended Product Life CycleExtended Product-Change NotificationProduct TraceabilityLow input bias currents: 500 pA (typical) (enables microamp current measurement)Low power:Low supply voltage, VS: 1.7 V to 5.5 VLow quiescent current: 50 µA at 25°C (typical)Accuracy:Common-mode rejection ratio: 132 dB (minimum)Gain error: ±0.2% (A1 device)Gain drift: 7 ppm/°C (maximum)Offset voltage, VOS: ±15 µV (maximum)Offset drift: 80 nV/°C (maximum)Wide common-mode voltage: –0.2 V to +40 VBidirectional current sensing capabilityGain options:INA190A1-EP: 25 V/VINA190A2-EP: 50 V/VINA190A3-EP: 100 V/VINA190A4-EP: 200 V/VINA190A5-EP: 500 V/VSupports Defense, Aerospace, and Medical Applications:Temperature range: –55°C to +150°C, TAControlled BaselineOne Assembly/Test SiteOne Fabrication SiteExtended Product Life CycleExtended Product-Change NotificationProduct TraceabilityLow input bias currents: 500 pA (typical) (enables microamp current measurement)Low power:Low supply voltage, VS: 1.7 V to 5.5 VLow quiescent current: 50 µA at 25°C (typical)Accuracy:Common-mode rejection ratio: 132 dB (minimum)Gain error: ±0.2% (A1 device)Gain drift: 7 ppm/°C (maximum)Offset voltage, VOS: ±15 µV (maximum)Offset drift: 80 nV/°C (maximum)Wide common-mode voltage: –0.2 V to +40 VBidirectional current sensing capabilityGain options:INA190A1-EP: 25 V/VINA190A2-EP: 50 V/VINA190A3-EP: 100 V/VINA190A4-EP: 200 V/VINA190A5-EP: 500 V/V

Description

The INA190-EP is a low-power, voltage-output, current-shunt monitor (also called a current-sense amplifier). This device is commonly used for overcurrent protection, precision current measurement for system optimization, or in closed-loop feedback circuits. The INA190-EP can sense drops across shunts at common-mode voltages from –0.2 V to +40 V, independent of the supply voltage. The low input bias current of the device permits the use of larger current-sense resistors, thus providing accurate current measurements in the microamp range. The low offset voltage of the zero-drift architecture extends the dynamic range of the current measurement. This feature allows for smaller sense resistors with lower power loss, while still providing accurate current measurements. The INA190-EP operates from a single 1.7-V to 5.5-V power supply, and draws a maximum of 65 µA of supply current when enabled; only 0.1 µA when disabled. Five fixed gain options are available: 25 V/V, 50 V/V, 100 V/V, 200 V/V, or 500 V/V. The device is specified over the operating temperature range of –55°C to +150°C, and offered in the SOT-23 package. The INA190-EP is a low-power, voltage-output, current-shunt monitor (also called a current-sense amplifier). This device is commonly used for overcurrent protection, precision current measurement for system optimization, or in closed-loop feedback circuits. The INA190-EP can sense drops across shunts at common-mode voltages from –0.2 V to +40 V, independent of the supply voltage. The low input bias current of the device permits the use of larger current-sense resistors, thus providing accurate current measurements in the microamp range. The low offset voltage of the zero-drift architecture extends the dynamic range of the current measurement. This feature allows for smaller sense resistors with lower power loss, while still providing accurate current measurements. The INA190-EP operates from a single 1.7-V to 5.5-V power supply, and draws a maximum of 65 µA of supply current when enabled; only 0.1 µA when disabled. Five fixed gain options are available: 25 V/V, 50 V/V, 100 V/V, 200 V/V, or 500 V/V. The device is specified over the operating temperature range of –55°C to +150°C, and offered in the SOT-23 package.
