G11MH7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT, STY 1, SZ
| Part | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Insert Material | Voltage Rating | Ingress Protection | Primary Material | Mounting Feature | Mounting Type | Current Rating (Amps) | Connector Type | Fastening Type | Color | Applications | Material Flammability Rating | Contact Material | Orientation | Shell Size - Insert | Shielding | Number of Positions | Termination | Shell Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Gold | 120 °C | -50 °C | Polyetheretherketone (PEEK) | 36 VDC | IP50 - Dust Protected | Plastic | Bulkhead - Rear Side Nut | Panel Mount Through Hole | 6 A | Receptacle Female Sockets | Detent Lock Push-Pull | Gray Green | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | Brass | H | 1 | Unshielded | 7 | Solder | Polysulfone (PSU) | |
Gold | 120 °C | -50 °C | Polyetheretherketone (PEEK) | 48 VDC | IP50 - Dust Protected | Plastic | Bulkhead - Rear Side Nut | Panel Mount | 12 Amps | Receptacle Female Sockets | Detent Lock Push-Pull | Gray | Industrial Medical Testing Equipment & Measurement | UL94 V-0 | Brass | H | 1 | Unshielded | 2 | Polysulfone (PSU) |
