RFAA4240 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
RF / COAXIAL ADAPTER, 2.4MM COAXIAL, JACK, 2.4MM COAXIAL, JACK, STRAIGHT PANEL ADAPTER, 50 OHM
| Part | Center Contact Material | Mating Cycles | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Body Material | Mounting Feature | Center Gender | Convert From (Adapter End) | Convert From (Adapter End) | Conversion Type | Frequency - Max [Max] | Adapter Series [Max] | Adapter Series [Min] | Style | Impedance | Mounting Type | Adapter Type | Convert To (Adapter End) | Convert To (Adapter End) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Beryllium Copper | 500 | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | 85 °C | -40 C | Stainless Steel | Flange | Female to Female | APC-2.4 Female Socket Jack OS-50 | 2.4 mm | Same Series | 50 GHz | 2.4 mm | 2.4 mm | Straight | 50 Ohms | Panel Mount | Jack to Jack | 2.4 mm | (APC-2.4 OS-50) Jack Female Socket |
