003800 Series

Manufacturer: Molex

Catalog

Catalog

CONN HEADER VERT 5POS 5.08MM

...

Part	Applications	Contact Finish - Post	Number of Rows	Material Flammability Rating	Contact Length - Mating	Contact Length - Mating	Number of Positions	Contact Shape	Contact Material	Shrouding	Termination	Insulation Color	Style	Number of Positions Loaded	Overall Contact Length [x]	Overall Contact Length [x]	Connector Type	Insulation Height [z]	Insulation Height	Contact Length - Post	Contact Length - Post	Fastening Type	Pitch - Mating	Pitch - Mating	Mounting Type	Insulation Material	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Voltage Rating	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height [z]	Features	Number of Positions Loaded	Insulation Height	Overall Contact Length	Overall Contact Length	Current Rating (Amps)
Molex 0038007487	General Purpose Industrial Telecommunications	Tin	1	UL94 V-2	11.43 mm	0.45 in	5	Circular	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Board Cable	4	19.05 mm	0.75 in	Header	0.375 in	9.53 mm	4.45 mm	0.175 in	Push-Pull	0.2 "	5.08 mm	Through Hole	Nylon 6/6 Polyamide (PA66)	Male Pin	100 çin	2.54 çm
Molex 0038001338	Automotive General Purpose Medical Telecommunications	Tin	1	UL94 V-0			8	Square	Phosphor Bronze		Solder	White	Board to Board Cable				Receptacle	0.185 in		3.35 mm	0.132 in	Push-Pull	0.1 "	2.54 mm	Board Edge Right Angle Through Hole	Nylon Polyamide (PA)	Cat Ear Female Non-Gendered	100 çin	2.54 çm	2.54 µm	100 µin	250 VAC	4 A	-40 C	105 ░C	4.7 mm	Board Hooks	All
Molex 0038006296	Automotive General Purpose Medical Telecommunications	Tin	1	UL94 V-0	7.15 mm	0.281 in	6	Square	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Cable/Wire				Header		11.7 mm	10 mm	0.394 in	Friction Lock	0.1 "	2.54 mm	Through Hole	Nylon Polyamide (PA)	Male Pin	60 µin	1.52 Ám	1.52 µm	60 µin							All	0.461 in	20.32 mm	0.8 in
Molex 0038001333	Automotive General Purpose Medical Telecommunications	Tin	1	UL94 V-0				Square	Phosphor Bronze		Solder	White	Board to Board Cable				Receptacle	0.185 in		3.35 mm	0.132 in	Push-Pull	0.1 "	2.54 mm	Board Edge Right Angle Through Hole	Nylon Polyamide (PA)	Cat Ear Female Non-Gendered	100 çin	2.54 çm	2.54 µm	100 µin	250 VAC	4 A	-40 C	105 ░C	4.7 mm	Board Hooks	All
Molex 0038007097		Tin	1	UL94 V-2	11.43 mm	0.45 in	8	Circular	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Cable/Wire		19.05 mm	0.75 in	Header	0.375 in	9.53 mm	4.45 mm	0.175 in	Push-Pull	0.2 "	5.08 mm	Through Hole	Nylon 6/6 Polyamide (PA66)	Male Pin	100 çin	2.54 çm	2.54 µm	100 µin	600 VAC		-40 C	80 °C							Varies by Wire Gauge
Molex 0038001397	Automotive General Purpose Medical Telecommunications	Tin	1	UL94 V-0			7	Square	Phosphor Bronze		Solder	White	Board to Board Cable				Receptacle Receptacle Bottom Entry		7.9 mm	3.6 mm	0.142 in	Push-Pull	0.1 "	2.54 mm	Through Hole	Nylon Polyamide (PA)	Cat Ear Female Non-Gendered	100 çin	2.54 çm	2.54 µm	100 µin	250 VAC	4 A	-40 C	105 ░C		Board Hooks	All	0.311 in
Molex 0038006293	Automotive General Purpose Medical Telecommunications	Tin	1	UL94 V-0	7.15 mm	0.281 in		Square	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Cable/Wire				Header		11.7 mm	10 mm	0.394 in	Friction Lock	0.1 "	2.54 mm	Through Hole	Nylon Polyamide (PA)	Male Pin	60 µin	1.52 Ám	1.52 µm	60 µin							All	0.461 in	20.32 mm	0.8 in
Molex 0038007262		Tin	1	UL94 V-0			5	Square	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Cable/Wire				Header		11.7 mm			Push-Pull	0.156 in	3.96 mm	Through Hole	Nylon Polyamide (PA)	Male Pin	60 µin	1.52 Ám	1.52 µm	60 µin							All	0.461 in
Molex 0038001208	General Purpose Industrial Telecommunications	Tin	1	UL94 V-2	11.43 mm	0.45 in	7	Circular	Brass	Shrouded - 1 Wall	Solder	Natural	Board to Board Cable		19.05 mm	0.75 in	Header	0.375 in	9.53 mm	4.45 mm	0.175 in	Push-Pull	0.2 "	5.08 mm	Through Hole	Nylon 6/6 Polyamide (PA66)	Male Pin	100 çin	2.54 çm
