8446 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 6CON 18AWG/22AWG CHRM
| Part | Conductor Strand [custom] | Conductor Strand [custom] | Number of Conductors | Conductor Insulation | Conductor Material | Wire Gauge | Ratings | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Jacket (Insulation) Material | Usage | Length | Length | Cable Type | Operating Temperature [Max] | Operating Temperature [Min] | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 7 Strands 19 | 30 | 6 | Poly-Vinyl Chloride (PVC) | Copper Tinned | 18 AWG 22 AWG | UL Style 2576 | 0.813 mm | 0.032 in | 0.236 " | 5.99 mm | Chrome | Poly-Vinyl Chloride (PVC) | Audio Control Instrumentation | 152.4 m | 500 ft | Multi-Conductor | 80 °C | -20 ░C | ||
Belden Inc. | 7 Strands 19 | 30 | 6 | Poly-Vinyl Chloride (PVC) | Copper Tinned | 18 AWG 22 AWG | UL Style 2576 | 0.813 mm | 0.032 in | 0.236 " | 5.99 mm | Chrome | Poly-Vinyl Chloride (PVC) | Audio Control Instrumentation | 152.4 m | 500 ft | Multi-Conductor | 80 °C | -20 ░C | ||
Belden Inc. | 7 Strands 19 | 30 | 6 | Poly-Vinyl Chloride (PVC) | Copper Tinned | 18 AWG 22 AWG | UL Style 2576 | 0.813 mm | 0.032 in | 0.236 " | 5.99 mm | Chrome | Poly-Vinyl Chloride (PVC) | Audio Control Instrumentation | 304.8 m | 1000 ft | Multi-Conductor | 80 °C | -20 ░C | ||
 Belden Inc. | 7 Strands 19 | 30 | 6 | Poly-Vinyl Chloride (PVC) | Copper Tinned | 18 AWG 22 AWG | UL Style 2576 | 0.813 mm | 0.032 in | 0.236 " | 5.99 mm | Chrome | Poly-Vinyl Chloride (PVC) | Audio Control Instrumentation | Multi-Conductor | 80 °C | -20 ░C | 100 ft | 30.5 m |
