ESD1014 Series
ESD Protection Array, Low Capacitance, for High Speed Data Lines
Manufacturer: ON Semiconductor
Catalog
ESD Protection Array, Low Capacitance, for High Speed Data Lines
Key Features
• Low capacitance (3 pF maximum between I/O lines)
• ESD rating of Class 3B (exceeding 8 kV) per Human Body model and Class C (exceeding 400 V) per Machine Model
• Protection for IEC standards IEC 6100042 (ESD) Level 4 30 kV (Contact)
Description
AI
The ESD1014 is designed to protect high speed data lines from ESD, EFT and lightning surge.
