E2E2-X18 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SENSOR PROX INDUCTIVE 18MM CYL
| Part | Output Type | Package / Case | Termination Style | Shielding | Indicator [custom] | Ingress Protection | Material - Body | Sensing Distance | Sensing Distance | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensor Type | Operating Temperature [Max] | Operating Temperature [Min] | Response Frequency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | SCR-NO 2-Wire | Cylinder Threaded - M30 | Cable Leads | Unshielded | LED | IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 4 NEMA 6 | Nickel-Plated Brass | 18 mm | 0.709 in | 20 VAC | 264 VAC | Inductive | 85 °C | -40 °C | 25 Hz |
Omron Electronics Inc-EMC Div | SCR-NO 2-Wire | Cylinder Threaded - M30 | Cable Leads | Unshielded | LED | IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 4 NEMA 6 | Nickel-Plated Brass | 18 mm | 0.709 in | 20 VAC | 264 VAC | Inductive | 85 °C | -40 °C | 25 Hz |
 Omron Electronics Inc-EMC Div | NPN-NO 3-Wire | Cylinder Threaded - M30 | Connector | Unshielded | LED | IP67 | Nickel-Plated Brass | 18 mm | 0.709 in | 10 VDC | 55 V | Inductive | 85 °C | -40 °C | 100 Hz |
 Omron Electronics Inc-EMC Div | SCR-NC 2-Wire | Cylinder Threaded - M30 | Cable Leads | Unshielded | LED | IP67 | Nickel-Plated Brass | 18 mm | 0.709 in | 20 VAC | 264 VAC | Inductive | 85 °C | -40 °C | 25 Hz |
 Omron Electronics Inc-EMC Div | SCR-NO 2-Wire | Cylinder Threaded - M30 | Connector | Unshielded | LED | IP67 | Nickel-Plated Brass | 18 mm | 0.709 in | 20 VAC | 264 VAC | Inductive | 85 °C | -40 °C | 25 Hz |
