826633 Series

Catalog

CONN HEADER VERT 20POS 2.54MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Number of Rows [custom]	Contact Length - Post	Contact Length - Post	Insulation Color	Contact Finish - Post	Connector Type	Contact Finish - Mating	Mounting Type	Termination	Current Rating (Amps)	Number of Positions	Overall Contact Length [x]	Overall Contact Length [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Shape	Style	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions Loaded	Fastening Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Length - Mating	Contact Length - Mating	Insulation Material	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Material	Shrouding	Contact Type
TE Connectivity AMP Connectors 1-826633-0	118.1 µin	3 µm	2	2.5 mm	0.098 in	Green	Tin	Header Breakaway	Gold	Through Hole	Solder	5 A	20	12 mm	0.472 in	3.9 µin	0.099 µm	Square	Board to Board Cable	0.1 in	2.54 mm	All	Push-Pull	105 ░C	-65 ░C	6.7 mm	0.264 in	Polybutylene Terephthalate (PBT)	0.1 "	2.54 mm	UL94 V-0	Brass	Unshrouded	Male Pin
