833-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 32POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Material | Read Out | Contact Finish Thickness | Contact Finish Thickness | Color | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Number of Rows | Mounting Type | Pitch | Pitch | Number of Positions/Bay/Row | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Termination | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Dual | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Dual Edge | Through Hole | 3.96 mm | 0.156 in | 16 | Female | M3 Threaded Insert Top Mount Opening | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | Flush Mount M3 Threaded Insert Top Opening | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Dual | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Dual Edge | Board Edge Straddle Mount | 3.96 mm | 0.156 in | 16 | Female | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | 2 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Right Angle Through Hole | 3.96 mm | 0.156 in | 32 | Female | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Dual | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Dual Edge | Through Hole | 3.96 mm | 0.156 in | 16 | Female | Flush Mount M3 Threaded Insert Top Opening | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Single | 0.25 Ám | 10 Áin | Green | 125 °C | -40 C | Non Specified - Single Edge | 1 | Through Hole | 3.96 mm | 0.156 in | 32 | Female | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Gold | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap |
