093001612 Series
Manufacturer: HARTING
Beta
⌘K
16B SURFACE MOUNT HOUSING, DOUBLE LEVER, LOW CONSTRUCTION, 1XPG21 W/ METAL LEVERS
| Part | Connector Type | Thread Size | Housing Color | Size | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Lock Location | Style | Housing Finish | Housing Material | Operating Temperature [Max] | Operating Temperature [Min] | Ingress Protection | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | Base - Box Mount | PG21 | Gray | 16 B | 117 mm | 2.244 " | 2.205 " | 57 mm | 56 mm | 4.606 in | Locking Clip (2) on Base Bottom | Side Entry | Powder Coated | Aluminum Die Cast | 125 °C | -40 C | IP65 - Dust Tight Water Resistant | |
 HARTING | Base - Box Mount | PG21 | Gray | 16 B | 117 mm | 2.244 " | 2.205 " | 57 mm | 56 mm | 4.606 in | Locking Clip (1) on Base Bottom | Side Entry | Powder Coated | Aluminum Die Cast | 125 °C | -40 C | IP65 - Dust Tight Water Resistant | Feed Through |
