SF-2410 Series

Catalog

FUSE, SMD, 12A, FAST ACTING, 2410

Part	DC Cold Resistance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Breaking Capacity @ Rated Voltage	Approval Agency	Voltage Rating - AC	Mounting Type	Voltage Rating - DC	Melting I²t	Fuse Type	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Response Time	Package / Case	Melting I˛t
Bourns Inc. SF-2410F1200W-2	0.0053 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	65 V	Surface Mount	65 VDC	49.2	Board Mount (Cartridge Style Excluded)	12 Amps	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
Bourns Inc. SF-2410FP400W-2	0.0172 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	125 V	Surface Mount	125 VDC	4.1	Board Mount (Cartridge Style Excluded)	4 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
Bourns Inc. SF-2410FP050W-2	0.231 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A 100 A	UL	250 V	Surface Mount	125 VDC	0.1	Board Mount (Cartridge Style Excluded)	0.5 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)	0.1
Bourns Inc. SF-2410FP630W-2	0.01 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	125 V	Surface Mount	125 VDC	12.5	Board Mount (Cartridge Style Excluded)	6.3 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
Bourns Inc. SF-2410FP800W-2	0.0086 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	125 V	Surface Mount	125 VDC	20.3 I²t	Board Mount (Cartridge Style Excluded)	8 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
Bourns Inc. SF-2410FP200W-2	0.042 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A 100 A	UL	250 V	Surface Mount	125 VDC	2.75	Board Mount (Cartridge Style Excluded)	2 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)	2.75
Bourns Inc. SF-2410FP100W-2	0.093 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A 100 A	UL	250 V	Surface Mount	125 VDC	0.59 I²t	Board Mount (Cartridge Style Excluded)	1 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
Bourns Inc. SF-2410F1500W-2	0.0038 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	65 V	Surface Mount	65 VDC	102.5 I²t	Board Mount (Cartridge Style Excluded)	15 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)	102.5
Bourns Inc. SF-2410FP063W-2	0.174 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A 100 A	UL	250 V	Surface Mount	125 VDC	0.16 I²t	Board Mount (Cartridge Style Excluded)	0.63 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)	0.16
Bourns Inc. SF-2410FP250W-2	0.031 Ohms	0.098 in	0.24 "	2.49 mm	6.1 mm	0.085 in	2.16 mm	50 A	UL	125 V	Surface Mount	125 VDC	1.21	Board Mount (Cartridge Style Excluded)	2.5 A	-55 C	125 °C	Fast Blow	2410 (6125 Metric)
