89901 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 8COND 20AWG GRAY
| Part | Shield Coverage | Shield Material | Conductor Material | Operating Temperature [Max] | Operating Temperature [Min] | Length | Length | Conductor Strand [custom] | Conductor Strand [custom] | Shield Type | Number of Conductors | Jacket Color | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Insulation | Features | Cable Type | Wire Gauge | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 95 % 100 % | Aluminum Copper Tinned | Copper Tinned | 150 °C | -20 ░C | 152.4 m | 500 ft | 28 AWG | 7 | Braid Foil | 8 | Gray | 0.406 mm | 0.016 in | Plenum Polyvinylidene Fluoride (PVDF) | 0.37 in | 9.4 mm | Fluorinated Ethylene-Propylene (FEP) Foam Fluorinated Ethylene-Propylene (FFEP) | Drain Wire | Multi-Pair | 20 AWG | 300 VDC |
Belden Inc. | 95 % 100 % | Aluminum Copper Tinned | Copper Tinned | 150 °C | -20 ░C | 304.8 m | 1000 ft | 28 AWG | 7 | Braid Foil | 8 | Gray | 0.406 mm | 0.016 in | Plenum Polyvinylidene Fluoride (PVDF) | 0.37 in | 9.4 mm | Fluorinated Ethylene-Propylene (FEP) Foam Fluorinated Ethylene-Propylene (FFEP) | Drain Wire | Multi-Pair | 20 AWG | 300 VDC |
