D38999/24WJ Series

Manufacturer: Conesys

Catalog

CONN RCPT FMALE 61POS CRIMP

Part	Orientation	Primary Material	Connector Type	Mounting Feature	Shell Size, MIL	Mounting Type	Number of Positions	Contact Material	Current Rating (Amps)	Termination	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Color	Shell Finish	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Shielding	Ingress Protection	Insert Material	Fastening Type	Shell Material	Qualification	Contact Shape	Note	Housing Color	Grade	Contact Type	Type	Contact Size	Material Flammability Rating	Voltage Rating	Contact Size
Conesys D38999/24WJ61SA	A	Metal	Receptacle Female Sockets	Bulkhead - Front Side Nut	J	Panel Mount	61	Copper Alloy	7.5 A	Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	61	-65 ░C	175 °C	Aviation Marine Military	Shielded	IP67 - Dust Tight Waterproof	Thermoplastic	Threaded	Aluminum
Conesys D38999/24WJ8AN	N (Normal)		Receptacle Housing	Bulkhead - Front Side Nut	J	Panel Mount	8								Cadmium	25	8	-65 ░C	175 °C		Shielded	Environment Resistant		Threaded	Aluminum	MIL-DTL-38999 Series III	Circular	Contacts Not Included	Olive Drab	Military	Crimp	For Male Pins	8 Twinax
Conesys D38999/24WJ61PN	N (Normal)	Metal	Receptacle Male Pins	Bulkhead - Front Side Nut		Panel Mount	61	Copper Alloy		Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	61	-65 ░C	125 °C 175 °C	Aerospace Marine Military		Environment Resistant Waterproof	Thermoplastic	Threaded	Aluminum Alloy	MIL-DTL-38999 Series III				Military				UL94 V-0	500 VAC
Conesys D38999/24WJ8AA	A		Receptacle Housing	Bulkhead - Front Side Nut	J	Panel Mount	8								Cadmium	25	8	-65 ░C	175 °C		Shielded	Environment Resistant		Threaded	Aluminum	MIL-DTL-38999 Series III	Circular	Contacts Not Included	Olive Drab	Military	Crimp	For Male Pins	8 Twinax
Conesys D38999/24WJ61SN	N (Normal)	Metal	Receptacle Female Sockets	Bulkhead - Front Side Nut		Panel Mount	61			Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	61	-65 ░C	175 °C			Environment Resistant		Threaded	Aluminum Alloy
Conesys D38999/24WJ61PB	B	Metal	Receptacle Male Pins	Bulkhead - Front Side Nut		Panel Mount	61			Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	61	-65 ░C	175 °C			Environment Resistant		Threaded	Aluminum Alloy
Conesys D38999/24WJ61SB	B	Metal	Receptacle Female Sockets	Bulkhead - Front Side Nut		Panel Mount	61			Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	61	-65 ░C	175 °C			Environment Resistant		Threaded	Aluminum Alloy
Conesys D38999/24WJ35PC	C	Metal	Receptacle Male Pins	Bulkhead - Front Side Nut	J	Panel Mount	128	Copper Alloy		Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium			-65 ░C	175 °C	Aerospace Aviation Military	Shielded	Environment Resistant		Threaded	Aluminum
Conesys D38999/24WJ61AA	A	Metal	Receptacle Housing	Bulkhead - Front Side Nut	J	Panel Mount	61								Cadmium over Electroless Nickel	25	61	-65 ░C	175 °C		Shielded Unshielded	Environment Resistant	Plastic	Threaded	Aluminum Alloy	MIL-DTL-38999	Circular	Contacts Not Included	Olive Drab	Military	Crimp	For Male Pins				20
Conesys D38999/24WJ8SN	N (Normal)	Metal	Receptacle Female Sockets	Bulkhead - Front Side Nut	J	Panel Mount	8	Copper Alloy		Crimp	Gold	50 µin	1.27 µm	Olive Drab	Olive Drab Cadmium	25	8	-65 ░C	125 °C 175 °C	Aerospace Aviation Military	Shielded	Environment Resistant Waterproof		Threaded	Aluminum	MIL-DTL-38999 Series III				Military				UL94 V-0	500 VAC
