859-003 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 3P GOLD SLDR CUP
| Part | Applications | Contact Finish - Mating | Shell Material | Connector Type | Voltage Rating | Color | Mounting Feature | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Shielding | Insert Material | Shell Finish | Primary Material | Material Flammability Rating | Ingress Protection | Orientation | Mounting Type | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shell Size - Insert | Fastening Type | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Industrial Medical | Gold | Brass | Plug Female Sockets | 250 V | Silver | Bulkhead - Front Side Nut | 85 °C | -40 C | 4 A | Shielded | Polybutylene Terephthalate (PBT) | Nickel | Metal | UL94 V-0 | IP67 - Dust Tight Waterproof | A | Panel Mount | Brass | 0.25 µm | 10 µin | M12-3 | Threaded | |
 NorComp Inc. | Industrial Medical | Gold | Brass | Plug Female Sockets | 250 V | Silver | Bulkhead - Front Side Nut | 85 °C | -40 C | 4 A | Shielded | Polybutylene Terephthalate (PBT) | Nickel | Metal | UL94 V-0 | IP67 - Dust Tight Waterproof | A | Panel Mount | Brass | M12-3 | Threaded | Flash | ||
 NorComp Inc. | Industrial Medical | Gold | Copper Alloy | Receptacle Male Pins | 250 V | Silver | Bulkhead - Front Side Nut | 85 °C | -40 C | 4 A | Shielded | Polybutylene Terephthalate (PBT) | Nickel | Metal | UL94 V-0 | IP67 - Dust Tight Waterproof | A | Panel Mount | Brass | 0.25 µm | 10 µin | M12-3 | Threaded |
