VOF-60C Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 9V 59W
| Part | Type | Standard Number | Voltage - Input [Min] | Voltage - Input [Max] | Voltage - Isolation | Mounting Type | Number of Outputs | Applications | Voltage - Output 1 | Features | Efficiency | Approval Agency | Current - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Open Frame | 55024 55032 Class A 62368-1 | 85 VAC 100 V | 264 VAC 370 VDC | 3000 V | Chassis Mount | 1 | ITE (Commercial) | 9 V | Universal Input | 83 % | CB Scheme EN IEC UL | 6.6 A | 70 °C | -25 °C | 50.8 mm | 1.18 in | 2 in | 3 " | 76.2 mm | 30 mm | 59 W |
CUI Inc. | Open Frame | 55024 55032 Class A 62368-1 | 85 VAC 100 V | 264 VAC 370 VDC | 3000 V | Chassis Mount | 1 | ITE (Commercial) | 24 V | Universal Input | 87 % | CB Scheme EN IEC UL | 2.5 A | 70 °C | -25 °C | 50.8 mm | 1.18 in | 2 in | 3 " | 76.2 mm | 30 mm | 60 W |
CUI Inc. | Open Frame | 55024 55032 Class A 62368-1 | 85 VAC 100 V | 264 VAC 370 VDC | 3000 V | Chassis Mount | 1 | ITE (Commercial) | 5 V | Universal Input | 80 % | CB Scheme EN IEC UL | 10 A | 70 °C | -25 °C | 50.8 mm | 1.18 in | 2 in | 3 " | 76.2 mm | 30 mm | 50 W |
CUI Inc. | Open Frame | 55024 55032 Class A 62368-1 | 85 VAC 100 V | 264 VAC 370 VDC | 3000 V | Chassis Mount | 1 | ITE (Commercial) | 12 V | Universal Input | 85 % | CB Scheme EN IEC UL | 5 A | 70 °C | -25 °C | 50.8 mm | 1.18 in | 2 in | 3 " | 76.2 mm | 30 mm | 60 W |
