9985 Series

Catalog

HOOK-UP STRND 26AWG GRN 100'

Part	Conductor Strand [x]	Conductor Strand [x]	Length [x]	Length [x]	Jacket Color	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Cable Type	Conductor Material	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage	Length	Length
Belden Inc. 9985 005100	34 AWG	7	100 ft	30.5 m	Green	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
Belden Inc. 9985 0041000	34 AWG	7			Yellow	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC	304.8 m	1000 ft
Belden Inc. 9985 003100	34 AWG	7	100 ft	30.5 m	Orange	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
Belden Inc. 9985 013100	34 AWG	7	100 ft	30.5 m	Blue	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
Belden Inc. 9985 009100	34 AWG	7	100 ft	30.5 m	White	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
Belden Inc. 9985 0101000	34 AWG	7			Black	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC	304.8 m	1000 ft
Belden Inc. 9985 0091000	34 AWG	7			White	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC	304.8 m	1000 ft
Belden Inc. 9985 004100	34 AWG	7	100 ft	30.5 m	Yellow	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
Belden Inc. 9985 0021000	34 AWG	7			Red	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC	304.8 m	1000 ft
Belden Inc. 9985 001100	34 AWG	7	100 ft	30.5 m	Brown	UL Style 1061	0.99 mm	0.039 in	26 AWG	Hook-Up	Copper Tinned	Poly-Vinyl Chloride (PVC)	0.25 mm	0.01 in	300 VDC
