837-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 32POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Pitch | Pitch | Color | Gender | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Type | Number of Rows | Contact Finish | Card Type | Flange Feature | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.156 " | 3.96 mm | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.116 " | 2.95 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | Floating Bobbin Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 16 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | Dual | Cantilever | Gold | Non Specified - Dual Edge | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 32 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | Single | Cantilever | 1 | Gold | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 16 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.116 " | 2.95 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | Dual | Cantilever | Gold | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 2 | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 16 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.156 " | 3.96 mm | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | Dual | Cantilever | Gold | Non Specified - Dual Edge | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 16 | 3.96 mm | 0.156 in | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.128 " | 3.25 mm | Solder | Through Hole | 0.25 Ám | 10 Áin | Dual | Cantilever | Gold | Non Specified - Dual Edge | 2 | 2 |
