DC12.4202 Series

Catalog

PWR ENT MOD RCPT IEC320-C18 PNL

Part	Ingress Protection	Voltage Rating - Appliance Inlet	Material Flammability Rating	Features	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Approval Agency	Switch Features	Number of Positions	Mounting Type	Filter Type	Connector Type	Connector Style	Current Rating - Filter	Current Rating - Appliance Inlet	Termination	Termination	Termination
SCHURTER Inc. DC12.4202.131	IP40	250 VAC	UL94 V-0	Shielded V-Lock Notch	0.118 in	3 mm	1 mm	0.039 in	33.1 mm	29.4 mm	CQC cULus ENEC	Switch On-Off	2	Panel Mount Snap-In	Filtered (EMI RFI) - Commercial Medical	Receptacle Male Blades - Module	IEC 320-C18	6 A	10 A	6.3 mm	Quick Connect	0.25 "
SCHURTER Inc. DC12.4202.201	IP40	250 VAC	UL94 V-0	Shielded V-Lock Notch					34.4 mm	30.4 mm	CQC cULus ENEC	Switch On-Off		Flange Panel Mount	Filtered (EMI RFI) - Commercial Medical	Receptacle Male Blades - Module	IEC 320-C14	6 A	10 A	6.3 mm	Quick Connect	0.25 "
SCHURTER Inc. DC12.4202.121	IP40	250 VAC	UL94 V-0	Shielded V-Lock Notch	0.118 in	3 mm	1 mm	0.039 in	33.1 mm	29.4 mm	CQC cULus ENEC	Switch On-Off	2	Panel Mount Snap-In	Filtered (EMI RFI) - Commercial Medical	Receptacle Male Blades - Module	IEC 320-C18	6 A	10 A	6.3 mm	Quick Connect	0.25 "
SCHURTER Inc. DC12.4202.031	IP40	250 VAC	UL94 V-0	Shielded V-Lock Notch					33.1 mm	29.1 mm	CQC cULus ENEC	Switch On-Off	2	Flange Panel Mount	Filtered (EMI RFI) - Commercial Medical	Receptacle Male Blades - Module	IEC 320-C18	6 A	10 A	6.3 mm	Quick Connect	0.25 "
