846-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Color | Number of Rows [custom] | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Read Out | Mounting Type | Card Type | Contact Type | Pitch | Pitch | Contact Material | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 125 °C | -40 C | 10 | Dual | Right Angle Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 20 Bay/Row | Single | Through Hole | Non Specified - Single Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | 1 | 1 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | 20 Bay/Row | Single | Through Hole | Non Specified - Single Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 10 | Dual | Right Angle Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder Eyelet(s) | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 125 °C | -40 C | 10 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 20 Bay/Row | Single | Through Hole | Non Specified - Single Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 125 °C | -40 C | 10 | Dual | Right Angle Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | 0.156 " | 3.96 mm | 125 °C | -40 C | 20 Bay/Row | Single | Through Hole | Non Specified - Single Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 125 °C | -40 C | 10 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 2 | Solder | 0.156 " | 3.96 mm | 125 °C | -40 C | 10 | Dual | Through Hole | Non Specified - Dual Edge | Cantilever | 3.18 mm | 0.125 in | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 20 |
