GL6-P Series

Catalog

SENSOR RETROREFLECTIVE 5MM PNP

Part	Response Time	Adjustment Type	Ingress Protection	Voltage - Supply [Min]	Voltage - Supply [Max]	Connection Method	Output Configuration	Light Source	Sensing Distance	Sensing Distance	Operating Temperature [Min]	Operating Temperature [Max]	Sensing Method	Cable Length	Cable Length
SICK, Inc. 1058851	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Cable with Connector	PNP	RED (650nm)	5 mm	0.197 in	-25 °C	55 °C	Retroreflective	0.3 m	11.81 "
SICK, Inc. GL6-P7311	625 µs		IP67	10 VDC	30 VDC	Connector M12	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective	0.3 m	11.81 "
SICK, Inc. GL6-P4212	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Connector M8	PNP	RED (650nm)	5 mm	0.197 in	-25 °C	55 °C	Retroreflective
SICK, Inc. 1052966	625 µs		IP67	10 VDC	30 VDC	Connector M12	PNP	RED (650nm)	5 mm	0.197 in	-25 °C	55 °C	Retroreflective	0.3 m	11.81 "
SICK, Inc. GL6-P3211	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Connector M8	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective
SICK, Inc. GL6-P4511	625 µs		IP67	10 VDC	30 VDC	Connector M8	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective
SICK, Inc. GL6-P1211	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Cable	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective	2 m	78.74 "
SICK, Inc. 1060815	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Cable	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective	2 m	78.74 "
SICK, Inc. 1062753	625 µs	Adjustable Potentiometer	IP67	10 VDC	30 VDC	Cable with Connector	PNP	RED (650nm)	6 mm	0.236 in	-25 °C	55 °C	Retroreflective	0.3 m	11.81 "
SICK, Inc. 1050706	625 µs		IP67	10 VDC	30 VDC	Connector M8 4POS	PNP - Dark-ON/Light-ON - Selectable	Red LED	5 m 196.85 in		-25 °C	55 °C	Retroreflective
