3549H Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 5K OHM 2W HYBRITRON LINEAR
| Part | Size - Body [diameter] | Size - Body [diameter] | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Temperature Coefficient | Adjustment Type | Termination Style | Power (Watts) | Tolerance | Mounting Type | Built in Switch | Resistive Material | Resistance (Ohms) | Actuator Type | Number of Turns | Actuator Length [x] | Actuator Length [x] | Taper | Bushing Thread | Number of Gangs | Rotation | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 22.48 mm | 0.885 " | 6 mm | 0.236 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | 5 kOhms | Slotted | 10 | 20.6 mm | 0.811 in | Linear | M9 x 0.75 | 1 | 3600 ° | |
 Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | 5 kOhms | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | |
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | 10k | |
 Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 2 | 3600 ° | 10k | |
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | 10k | |
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | 10k | |
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 2 | 3600 ° | 1k | |
 Bourns Inc. | 22.23 mm | 0.875 " | 3.18 mm | 0.125 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Servo Mount | None | Hybritron® | Round | 10 | 9.53 mm | 0.375 in | Linear | 1 | 3600 ° | 10k | ||
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | 1k | |
Bourns Inc. | 22.48 mm | 0.885 " | 6.35 mm | 0.25 in | 100 ppm/°C | User Defined | Solder Lug | 2 W | 10 % | Panel Mount | None | Hybritron® | Slotted | 10 | 20.64 mm | 0.813 in | Linear | 3/8-32 | 1 | 3600 ° | 1k |
