2369991 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
4P MTA100 HDR HT FL 30 AU LF, OM
| Part | Contact Finish - Post | Style | Contact Length - Mating | Contact Length - Mating | Insulation Color | Contact Shape | Mounting Type | Overall Contact Length | Overall Contact Length | Contact Material | Number of Rows | Contact Finish - Mating | Insulation Height | Insulation Height | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shrouding | Material Flammability Rating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Pitch - Mating | Pitch - Mating | Contact Length - Post [x] | Contact Length - Post [x] | Connector Type | Termination | Contact Type | Number of Positions | Number of Positions Loaded | Fastening Type | Insulation Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | 7.49 mm | 0.295 in | Black | Square | Through Hole | 0.55 in | 13.97 mm | Copper Alloy | 1 | Gold | 0.347 in | 8.81 mm | 3 µin | 0.076 µm | Shrouded - 1 Wall | UL94 V-0 | 15 µin | 0.38 µm | 0.1 in | 2.54 mm | 0.135 in | 3.43 mm | Header | Solder | Male Pin | 4 | 2 | Friction Lock | Polyamide (PA4T) Nylon 4T |
