2250015 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
CONN JACK 1PORT 1000 BASE-T PCB
| Part | Tab Direction | Contact Finish | Number of Rows | Height Above Board [z] | Height Above Board [z] | Contact Finish Thickness | Contact Finish Thickness | Features | Number of Ports | Termination | Shield Material | Number of Cores per Jack | Contact Material | Mounting Type | Orientation | Connector Type | LED Color | Operating Temperature [Max] | Operating Temperature [Min] | Shielding | Housing Material | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Up | Gold | 1 | 0.539 in | 13.69 mm | 50 µin | 1.27 µm | Board Guide | 1 | Solder | Brass | 8 | Phosphor Bronze | Through Hole | 90 ° | RJ45 | Green Orange Yellow | 85 °C | -40 C | EMI Finger Shielded | Thermoplastic | 10/100/1000 Base-T AutoMDIX |
Bel Fuse Inc. | Up | Gold | 1 | 0.539 in | 13.69 mm | Board Guide | 1 | Solder | 8 | Phosphor Bronze | Through Hole | 90 ° | RJ45 | Green Orange Yellow | 85 °C | -40 C | EMI Finger Shielded | 10/100/1000 Base-T AutoMDIX |
