74LVC1G86 Series

Catalog

IC GATE XOR 1CH 2-INP 5TSSOP

Part	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Number of Circuits	Package / Case	Current - Output High, Low [y]	Current - Output High, Low [x]	Input Logic Level - High [Min]	Input Logic Level - High [Max]	Logic Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Max Propagation Delay @ V, Max CL	Number of Inputs	Current - Quiescent (Max) [Max]	Supplier Device Package
Freescale Semiconductor - NXP 74LVC1G86GW,165	0.8 V	0.7 V	1	5-TSSOP SC-70-5 SOT-353	32 mA	32 mA	1.7 V	2 V	XOR (Exclusive OR)	5.5 V	1.65 V	125 °C	-40 °C	Surface Mount	4 ns	2	4 µA	5-TSSOP
Freescale Semiconductor - NXP 74LVC1G86GM,115	0.8 V	0.7 V	1	6-XFDFN	32 mA	32 mA	1.7 V	2 V	XOR (Exclusive OR)	5.5 V	1.65 V	125 °C	-40 °C	Surface Mount	4 ns	2	4 µA	6-XSON SOT886 (1.45x1)
Freescale Semiconductor - NXP 74LVC1G86GX,125
Freescale Semiconductor - NXP 74LVC1G86GF/S500,1
Freescale Semiconductor - NXP 74LVC1G86GF,132	0.8 V	0.7 V	1	6-XFDFN	32 mA	32 mA	1.7 V	2 V	XOR (Exclusive OR)	5.5 V	1.65 V	125 °C	-40 °C	Surface Mount	4 ns	2	4 µA	6-XSON SOT891 (1x1)
