MHR-10 Series
Manufacturer: Adam Tech
Beta
⌘K
CONN EJECTOR HEADER HDR 10 POS 2.54MM SOLDER ST THRU-HOLE
| Part | Contact Finish Thickness - Post | Fastening Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Contact Finish Thickness - Mating | Style | Number of Positions | Insulation Material | Contact Length - Post [x] | Contact Length - Post | Contact Shape | Voltage Rating | Contact Finish - Post | Connector Type | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Number of Positions Loaded | Insulation Height | Insulation Height | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Shrouding | Number of Rows [custom] | Mounting Type | Contact Type | Insulation Color | Contact Material | Features | Insulation Height [z] | Current Rating (Amps) | Contact Length - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | Flash | Latch Lock/Eject Hooks Long | 0.1 in | 2.54 mm | Flash | Board to Cable/Wire | 10 | Polybutylene Terephthalate (PBT) Glass Filled | 0.134 " | 3.4 mm | Square | 250 VAC | Gold | Header | Solder | -40 C | 105 ░C | UL94 V-0 | All | 0.661 " | 16.79 mm | Gold | 0.1 " | 2.54 mm | Shrouded - 4 Wall | 2 | Through Hole | Male Pin | Black | Brass | ||||
 Adam Tech | Flash | Latch Lock/Eject Hooks Long | 0.1 in | 2.54 mm | Flash | Board to Cable/Wire | 10 | Polybutylene Terephthalate (PBT) | 3.6 mm | Square | 250 VAC | Gold | Header | Solder | -55 C | 105 ░C | UL94 V-0 | All | 8.4 mm | Gold | 0.1 " | 2.54 mm | Shrouded - 4 Wall | 2 | Right Angle Through Hole | Male Pin | Black | Brass | Keying Slot | 0.331 in | 3 A | 0.142 in | ||
 Adam Tech | Flash | Latch Lock/Eject Hooks | 0.1 in | 2.54 mm | Flash | Board to Cable/Wire | 10 | Polybutylene Terephthalate (PBT) | 0.157 in | 4 mm | Square | 250 VAC | Gold | Header | Solder | -55 C | 105 ░C | UL94 V-0 | All | 8.4 mm | Gold | 0.1 " | 2.54 mm | Shrouded - 4 Wall | 2 | Right Angle Through Hole | Male Pin | Black | Brass | Keying Slot | 0.331 in | 3 A | ||
Adam Tech | Latch Lock/Eject Hooks | 0.1 in | 2.54 mm | Flash | Board to Cable/Wire | 10 | Polybutylene Terephthalate (PBT) | 3.6 mm | Square | 250 VAC | Tin | Header | Solder | -55 C | 105 ░C | UL94 V-0 | All | 8.4 mm | Gold | 0.1 " | 2.54 mm | Shrouded - 4 Wall | 2 | Right Angle Through Hole | Male Pin | Black | Brass | Polarizing Key | 0.331 in | 3 A | 0.142 in | |||
 Adam Tech | Flash | Latch Lock/Eject Hooks | 0.1 in | 2.54 mm | Flash | Board to Cable/Wire | 10 | Polybutylene Terephthalate (PBT) | 0.134 " | 3.4 mm | Square | 250 VAC | Gold | Header | Solder | -55 C | 105 ░C | UL94 V-0 | All | 0.677 in | 17.2 mm | Gold | 0.1 " | 2.54 mm | Shrouded - 4 Wall | 2 | Through Hole | Male Pin | Black | Brass | 3 A |
