PFH500F Series
Manufacturer: TDK Corporation
Beta
⌘K
AC/DC PCB MOUNT POWER SUPPLY (PSU), 1 OUTPUT, 504 W, 28 V, 18 A
| Part | Load Regulation | Line Regulation | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Current - Output (Max) [Max] | Approval Agency | Voltage - Output 1 | Type | Package / Case | Features | Efficiency | Power (Watts) | Mounting Type | Number of Outputs | Applications | Voltage - Input [Max] | Voltage - Input [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 0.1 % | 0.15 % | -40 °C | 100 °C | 4 " | 0.53 in | 13.5 mm | 2.4 in | 61 mm | 101.6 mm | 18 A | CE cURus VDE | 28 V | Enclosed | Three Quarter Brick | Adjustable Output PFC PMBus™ Remote On/Off Remote Sense Standby Output Universal Input | 92 % | 504 W | Through Hole | 1 | ITE (Commercial) | 265 VAC | 85 VAC |
TDK Corporation | 0.1 % | 0.15 % | -40 °C | 100 °C | 4 " | 0.53 in | 13.5 mm | 2.4 in | 61 mm | 101.6 mm | 18 A | CE cURus VDE | 28 V | Enclosed | Three Quarter Brick | Adjustable Output Load Sharing PFC PMBus™ Interface Remote On/Off Remote Sense Standby Output Universal Input | 92 % | 504 W | Through Hole | 1 | ITE (Commercial) | 265 VAC | 85 VAC |
