V23234 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
POWER RELAY 12VDC 50A SPST-NO(28.5MM 28.5MM 25.3MM) PLUG-IN
| Part | Coil Resistance | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Contact Material | Contact Rating (Current) | Coil Current | Operate Time | Termination Style | Termination Style | Contact Form | Coil Type | Relay Type | Must Release Voltage | Must Operate Voltage | Release Time | Coil Voltage | Switching Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 85 Ohms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 30 A | 16.7 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 1.5 VDC | 8 VDC | 2 ms | 12 VDC | |
 TE Connectivity AMP Connectors | 85 Ohms | 125 °C | -40 C | Socketable | Silver Alloy | 30 A | 16.7 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPDT (1 Form C) | Non Latching | General Purpose | 1.5 VDC | 8 VDC | 7 ms | 12 VDC | 14 VDC |
TE Connectivity AMP Connectors | 85 Ohms | 125 °C | -40 C | Socketable | Silver Alloy | 30 A | 141.2 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPDT (1 Form C) | Non Latching | General Purpose | 1.5 VDC | 8 VDC | 7 ms | 12 VDC | |
 TE Connectivity AMP Connectors | 85 Ohms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 30 A | 141.2 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 1.5 VDC | 8 VDC | 2 ms | 12 VDC | |
TE Connectivity AMP Connectors | 1.4 kOhms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 20 A | 16.7 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 3 VDC | 16 VDC | 2 ms | 24 VDC | |
 TE Connectivity AMP Connectors | 255 Ohms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 20 A | 16.7 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 3 VDC | 16 VDC | 2 ms | 24 VDC | |
TE Connectivity AMP Connectors | 255 Ohms | 125 °C | -40 C | Socketable | Silver Alloy | 20 A | 94.1 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 3 VDC | 16 VDC | 2 ms | 24 VDC | 28 VDC |
TE Connectivity AMP Connectors | 75 Ohms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 30 A | 160 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPST-NO (1 Form A) | Non Latching | General Purpose | 1 VDC | 6.5 VDC | 2 ms | 12 VDC | |
TE Connectivity AMP Connectors | 255 Ohms | 125 °C | -40 C | Chassis Mount | Silver (Ag) | 20 A | 94.1 mA | 7 ms | 0.187 in 0.25 in | Quick Connect | SPDT (1 Form C) | Non Latching | General Purpose | 3 VDC | 16 VDC | 2 ms | 24 VDC |
